SZS230 top rotation type tablet sieving machine Uphill tablet deduster

Product Description

SZS230 Capsule Polisher rotary tablet sieving machine deduster

SZS series top spin sieve machine has utilized many advanced technologies in its creation. This top spin sieve machine is able to act as both elevating and dedusting machine, which made it an unusual combination with other tablet-compressing machine and metal detection machine, and also made it extremely applicable in the filed of pharmacy, chemical engineering, electronics, and food.

The machine can do the entrance and exit of 360 degrees of adjustment, convenient production, space saving, outstanding production efficiency, can meet the mass production of 3-35mm diameter of various shaped tablets; the new device design, so as to ensure the machine running smooth, low noise.

Details Images

Specification

Specification:

Its advantages include long dedusting path, automatic tablet polishing of all sides/angles, and high quality dedusting without damage to the tablets. The machine is also employed many new designs and features to ensuring better and safer operations. Furthermore, it can act as a delivering device for any shapes and sizes of tablets that need to be dedicated in dedusting. It is designed and manufactured in conformance to cover GMP standard.

It has an adjustable feeding height of 835-985mm and adjustable chute of 1070-1220mm, which is highly flexible to mount and enables the operator to remove dust and burrs from tablets in a process. Dust and burrs are removed from the tablets while they are being transported upwards by vibration through a continuous spiral. Additional features of the Uphill Deduster are variable throughput rates, height advantage for subsequent stages of the process and ready safe exhaust of the dust through a central suction pipe.

1	Max. capacity	800000pcs/h (For 0.6mm tablet)
2	Max. tablet diameter	Φ25mm
3	Power supply	1P, 220/110V, 50 ~ 60Hz
4	Machine size	550×550×(H: 1350 ~ 1500), mm
5	Machine weight	70Kg
6	Compressed air	0.1m3/min, 0.05Mpa
7	Vacuum dust collecting	2.7 m3/min, 0.01Mpa
8	Dust-collecting distance	6m
9	Max. lifting height	1220mm

Related products

Packing & Delivery

Company Profile

Liaoyang Xianglong Internaitional Machinery Trading Co., Ltd. is originated from Liaoyang Pharmaceutical Machinery Plant (which was the first state-owned pharmaceutical machinery plant in China and was founded in 1947), and is professional in the manufacturing & trading of variable kinds of pharmaceutical devices, including separating machines, drying machines, liquid /powder /capsule/ pills filling machine, cartonning machines, membrane packing machines and glass-lined tanks, etc. With professional technicians and strict quality control system, our machines are widely applied in industries of pharmaceutical, petrol, chemical, food and environment protecting, etc., and besides our regular customers in China, our machines have been exported to many countries & regions in Europe, America, Southeast Asia, Africa, South America and the Middle East, etc., and good reputation is gained.

FAQ

Q1: Are you a manufacturer or a trader?
A: As a professional manufacturer, we have our own factory, and if a customer has reasonable demand, out machine can be customized.

Q2: How do you ensure the machine quality?
A: As a professional manufacturer of pharmaceutical devices for more than 15years, with strict management, advanced
processing technologies and professional workers, we are confident for our machines quality. And before any
machine is delivered, will be carefully tested.

Q3: How can I trust you for the first cooperation?
A: Since our company was founded, we have registered in China Industry and Commerce Bureau. We passed the SGS &
ISO certification, and we are a senior member in Alibaba international platform (more than 12years). For the first deal between us, the Alibaba's Trade Assurance service can be used, which will fairly protect your rights and money throughout the transaction process.

Q4: How do I place an order, and how is it completed?
A: Under the condition that the buyer is satisfied with the quotation and pre-sales service:
1. Both of parties sign on a contract, and then the seller prepare the PI.
2. The buyer arranges the down payment.
3. The seller prepares the machines.
4. After the machine is completed, have the test & trial run.
5. Before the delivery, if the buyer requires, have the necessary inspecting.
6. As per the contract/ PI amount, the buyer balances the payment.
7. The machine is going to be shipped.
8. After the machine is received, the seller provide the buyer guidance for the installation and the debugging.
